| PartNumber | DMC-16117A |
| Brand | Kyocera |
| Size | 2.4 |
| Application | |
| Resolution | 16×1 |
| Composition | LCM |
| Brightness | |
| CR | |
| Colors | Monochrome |
| Backlight | No B/L |
| Interface | CPU |
| Panel Brand | OPTREX |
| Panel Model | DMC-16117A |
| Panel Type | TN-LCD , LCM |
| Panel Size | 2.4 inch |
| Display Format | 16 characters × 1 lines |
| Display Mode | TN, Reflective |
| Display Fonts | 5×8 dots |
| Character Size | 3.2×5.95 mm |
| Character Pitch | 3.75×5.95 mm |
| Active Area | 59.4×5.95 mm |
| Bezel Area | 64.5×13.0 mm |
| Outline | 80×36×10 mm |
| Contrast Ratio | 3.5:1 (Typ.)(Reflective) |
| Display Colors | Monochrome |
| Response Time | 180/130 (Typ.)(Tr/Td) |
| Lamp Type | No B/L |
| Signal Interface | 8-bit parallel, 14 pins |
| Input Voltage | 5.0V (Typ.) |
