| PartNumber | LS024Q8DD92 |
| Brand | SHARP |
| Size | 2.4 |
| Application | |
| Resolution | 240(RGB)×320 , QVGA |
| Composition | CELL |
| Brightness | 0 |
| CR | 100:1 |
| Colors | 65K/262K |
| Backlight | No B/L |
| Interface | TTL |
| Panel Brand | SHARP |
| Panel Model | LS024Q8DD92 |
| Panel Type | CG-Silicon , CELL |
| Panel Size | 2.4 inch |
| Display Mode | TN, Normally White, Transflective |
| Active Area | 36.72×48.96 mm |
| Outline | 41.2×58 mm |
| Surface | Hard coating (3H) |
| Glass Depth | 0.50+0.50 mm |
| Contrast Ratio | 100:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| Display Colors | 65K/262K |
| Response Time | 13/35 (Typ.)(Tr/Td) |
| Viewing Angle | 45/45/35/45 (Typ.)(CR≥3)(L/R/U/D) |
| Driver IC | Built-in uPD161831 |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 60 pins |
| Input Voltage | 3.0/3.0V (Typ.)(VCC/VDC) |
