| PartNumber | DLC0350SZG |
| Brand | Other |
| Size | 3.5 |
| Application | MPH |
| Resolution | 480(RGB)×640 , VGA |
| Composition | LCM |
| Brightness | 120 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | TTL |
| Panel Brand | DLC |
| Panel Model | DLC0350SZG |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 3.5 inch |
| Display Mode | Normally Black, Transflective |
| Active Area | 53.57×71.42 mm |
| Outline | 64×85×5.2 mm |
| Surface | |
| Contrast Ratio | 500:1 (Typ.)(Transmissive)5:1 (Typ.)(Reflective) |
| Display Colors | 262K (6-bit), CIE193155% |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 6S1PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| Input Voltage | 2.8/2.8V (Typ.)(IOVCC/VCC) |
