| PartNumber | DLC0350BMG-1 |
| Brand | Other |
| Size | 3.5 |
| Application | MPH |
| Resolution | 240(RGB)×320 , QVGA |
| Composition | LCM |
| Brightness | 100 cd/m² (Typ.) |
| CR | 150:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | TTL |
| Panel Brand | DLC |
| Panel Model | DLC0350BMG-1 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 3.5 inch |
| Display Mode | TN, Normally White, Transflective |
| Active Area | 53.64×71.52 mm |
| Outline | 64×85×3.13 mm |
| Surface | Hard coating |
| Contrast Ratio | 150:1 (Typ.)(Transmissive)6.5:1 (Typ.)(Reflective) |
| Display Colors | 262K (6-bit) |
| Response Time | 35 (Typ.)(Tr+Td) |
| Viewing Angle | 40/45/55/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 6S1PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit) + SPI, 50 pins |
| Input Voltage | 2.8/15/-10V (Typ.)(VCC/VGH/VGL) |
