| PartNumber | HSD050FMW2-D00 |
| Brand | HannStar |
| Size | 5.0 |
| Application | MPH |
| Resolution | 540(RGB)×960 , qHD |
| Composition | CELL |
| Brightness | 0 |
| CR | 700:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | |
| Panel Brand | HannStar |
| Panel Model | HSD050FMW2-D00 2 Compatible model |
| Panel Type | a-Si TFT-LCD , CELL |
| Panel Size | 5.0 inch |
| Display Mode | IPS Pro, Normally Black, Transmissive |
| Active Area | 62.046×110.304 mm |
| Outline | 65.1×117.9×0.4 mm |
| Surface | Without Polarizer |
| Glass Depth | 0.20+0.20 mm |
| Transmissivity | 3.82% (Typ.)(with Polarizer) |
| Contrast Ratio | 700:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Response Time | 10/20 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Driver IC | COG Suggest NT35516, NT35517, HX8389-B, RM68190, OTM9608A, OTM9605A |
