| PartNumber | LS050T1SX06 |
| Brand | SHARP |
| Size | 5.0 |
| Application | MPH |
| Resolution | 1080(RGB)×1920 , FHD |
| Composition | LCM |
| Brightness | 480 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Panel Brand | SHARP |
| Panel Model | LS050T1SX06 |
| Panel Type | CG-Silicon , LCM |
| Panel Size | 5.0 inch |
| Display Mode | New Mode2, Normally Black, Transmissive |
| Active Area | 61.884×110.016 mm |
| Outline | 64.3×116.6×1.5 mm |
| Surface | |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193171% |
| Response Time | 35 (Max.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 6S2PWLEDWithout Driver |
| Signal Interface | MIPI (4 data lanes), 34 pins |
| Input Voltage | 1.8/5.0/-5.0V (Typ.)(IOVDD/VSP/VSN) |
