| PartNumber | DLC0400KZG |
| Brand | Other |
| Size | 4.0 |
| Application | MPH |
| Resolution | 640(RGB)×1136 |
| Composition | LCM |
| Brightness | 580 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Panel Brand | DLC |
| Panel Model | DLC0400KZG 1 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 4.0 inch |
| Display Mode | IPS, Normally Black, Transmissive |
| Active Area | 49.92×88.608 mm |
| Outline | 53.8×96.4×1.53 mm |
| Surface | |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Response Time | 20 (Typ.)(Tr+Td); 25 (Typ.)(G to G) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 4S2PWLEDWithout Driver |
| Signal Interface | MIPI (4 data lanes), 22 pins |
| Input Voltage | 1.8/5.7/-5.7V (Typ.)(DVDD/AVDDH/AVDDN) |
