| PartNumber | DMF-50174 |
| Brand | OPTREX |
| Size | 5.7 |
| Application | Industrial |
| Resolution | 320×240 |
| Composition | STN-LCD, LCM |
| Brightness | |
| CR | |
| Colors | Monochrome |
| Backlight | CCFL |
| Interface | Parallel |
| Model | DMF-50174 |
| Diagonal Size | 5.7 inch |
| Type | STN-LCD, LCM |
| Pixel Format | 320×240 [QVGA] 70PPI |
| Configuration | Rectangle |
| Active Area | 115.17(H)×86.37(V) mm |
| Outline Dim. | 174(H)×112(V) ×14(D) mm |
| Bezel Area | 122.0(H)×92.0(V) mm |
| Treatment | - |
| View Direction | - |
| Response Time | - |
| Viewing Angle | - |
| Operating Mode | STN |
| Support Color | Monochrome |
| Light Source | CCFL , W/O Driver |
| Weight | - |
| Designed For | Industrial |
| Frame Rate | 70Hz |
| Touch Panel | Without |
| Interface Type | Parallel Data (1ch, 4-bit) , 14 pins Connector |
| Power Supply | 5.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| C555001 | SII | 5.7 | 320×240 |
| CLAA057VC01CW | CPT | 5.7 | 640×480 |
| DMF-50174ZNB-FW | Kyocera | 5.7 | 320×240 |
| DMF-50773NB-FW | Kyocera | 5.4 | 240×128 |
| DMF-50773NF-FW | Kyocera | 5.4 | 240×128 |
| DMF-50840NB-FW | Kyocera | 5.7 | 320×240 |
| DMF-51043NFU-FW-1 | Kyocera | 9.4 | 640×480 |
| LTA057A344F | TOSHIBA | 5.7 | 320×240 |
| TCG057QVLAC-G00 | Kyocera | 5.7 | 320×240 |
| TX14D12VM1CBA | KOE | 5.7 | 320×240 |
