| PartNumber | DMF5005N-EB |
| Brand | Kyocera |
| Size | 5.2 |
| Application | IA |
| Resolution | 240×64 |
| Composition | LCM |
| Brightness | 65 cd/m² (Typ.) |
| CR | 7:1 |
| Colors | Monochrome |
| Backlight | EL |
| Interface | CPU |
| Panel Brand | OPTREX |
| Panel Model | DMF5005N-EB |
| Panel Type | STN-LCD , LCM |
| Panel Size | 5.2 inch |
| Display Mode | STN, Transflective |
| Active Area | 127.16×33.88 mm |
| Outline | 180×65×12 mm |
| Surface | |
| Contrast Ratio | 7:1 (Typ.)(Transmissive) |
| Display Colors | Monochrome (1-bit) |
| Response Time | 160/160 (Typ.)(Tr/Td) |
| Viewing Angle | 34/32/36/35 (Typ.)(CR≥2)(L/R/U/D) |
| Frequency | 70Hz |
| Lamp Type | EL |
| Signal Interface | 8-bit parallel, 22 pins |
| Input Voltage | 5.0V (Typ.)(VCC) |
