| PartNumber | DV150X0M-N11 |
| Brand | BOE |
| Size | 15.0 |
| Application | Digital Signage |
| Resolution | 1024(RGB)×768, XGA, 85PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 12S4P |
| Interface | LVDS |
| Panel Brand | BOE |
| Panel Model | DV150X0M-N11 |
| Panel Size | 15.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 304.128(W)×228.096(H) mm |
| Bezel Opening | 306.5(W)×230.1(H) mm |
| Outline Size | 326.5(W)×253.5(H) ×9.7(D) mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | ADS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | 12S4P WLED , 50K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 930g |
| Signal Interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
