| PartNumber | DV190E0M-N11 |
| Brand | BOE |
| Size | 19.0 |
| Application | Digital Signage |
| Resolution | 1280×1024 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 2 strings WLED , 30K hours , No Driver |
| Interface | LVDS |
| Manufacturer | BOE |
| Model Name | DV190E0M-N11 |
| Screen Size | 19.0 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1280(RGB)×1024 (SXGA) 86PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 374.784 × 299.827 (H×V) |
| Outline(mm) | 396 × 324 × 10.4 (H×V×D) |
| Bezel Area(mm) | 376.78 × 303.0 (H×V) |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 14 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | HADS, Normally Black, Transmissive |
| Color Depth | 16.7M 72% NTSC |
| Mass | 1.52Kgs |
| Used for | Digital Signage |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
