| PartNumber | ED047TC2 |
| Brand | E Ink |
| Size | 4.7 |
| Application | Mobile Phone |
| Resolution | 540×960 |
| Composition | EPD, EPD |
| Brightness | |
| CR | |
| Colors | Grayscale |
| Backlight | No |
| Interface | Parallel |
| Model | ED047TC2 |
| Diagonal Size | 4.7 inch |
| Type | EPD, EPD |
| Pixel Format | 540×960 [qHD] 235PPI |
| Configuration | Rectangle |
| Active Area | 58.32(H)×103.68(V) mm |
| Outline Dim. | 62.5(H)×113.9(V) mm |
| Bezel Area | - |
| Treatment | Hard coating |
| View Direction | - |
| Response Time | 450 |
| Viewing Angle | - |
| Operating Mode | Reflective |
| Support Color | Grayscale |
| Light Source | No B/L |
| Weight | 12.0g |
| Designed For | Mobile Phone |
| Frame Rate | - |
| Touch Panel | Without |
| Interface Type | Parallel Data (1ch, 8-bit) Connector |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -25 ~ 70 °C |
| A047FW01 V0 | AUO | 4.7 | 480×272 |
| ED043CA-01D | Innolux | 4.3 | 480×272 |
| H466TAN01.0 | AUO | 4.7 | 720×1280 |
| H466TAN01.1 | AUO | 4.7 | 720×1280 |
| KCG047QV1AA-A21 | Kyocera | 4.7 | 320×240 |
| LH467WX1-SD01 | LG Display | 4.7 | 768×1280 |
| LM32K10 | SHARP | 4.7 | 320×240 |
| LS047T1SC02 | SHARP | 4.7 | 1080×1920 |
| PG320240C | Other | 4.7 | 320×240 |
| TM047NBH01 | Tianma | 4.7 | 480×272 |
