| PartNumber | EV121X0M-N10 |
| Brand | BOE |
| Size | 12.1 |
| Application | Industrial |
| Resolution | 1024×768 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 1200:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Diagonal Size | 12.1 inch |
| Pixel Format | 1024(RGB)×768 [XGA] 105PPI |
| Active Area | 245.76(H)×184.32(V) mm |
| Bezel Area | 249(H)×187.5(V) mm |
| Luminance | 500 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Support Color | 16.7M 72% NTSC |
| Weight | 520g (Max.) |
| Frame Rate | 60Hz |
| Interface Type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| Model | EV121X0M-N10 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 260.5(H)×204(V) ×9.2(D) mm |
| Treatment | - |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| Response Time | 25 (Typ.)(Tr+Td) |
| Operating Mode | ADS, Normally Black, Transmissive |
| Light Source | WLED , 50K hours , With LED Driver |
| Designed For | Industrial |
| Touch Panel | Without |
