| PartNumber | G070VAN01.1 |
| Brand | AUO |
| Size | 7.0 |
| Application | Industrial |
| Resolution | 800×480 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1300:1 |
| Colors | 262K/16.7M |
| Backlight | 7S2P WLED , 30K hours , No Driver |
| Interface | LVDS |
| Manufacturer | AUO |
| Screen Size | 7.0 inch |
| Pixel Number | 800×480(RGB) (WVGA) 133PPI |
| Active Area(mm) | 152.4 × 91.44 (H×V) |
| Bezel Area(mm) | 154.2 × 93.24 (H×V) |
| Luminance | 200 cd/m² (Typ.) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 262K/16.7M 60% NTSC |
| Mass | 160g (Typ.) |
| Refresh Rate | 60Hz |
| Signal Type | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| Model Name | G070VAN01.1 |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Horizontal Stripe |
| Outline(mm) | 166.6 × 107 × 10 (H×V×D) |
| Treatment | Antiglare |
| Contrast Ratio | 1300 : 1 (Typ.) (TM) |
| Response | 11/19 (Max.)(Tr/Td) ms |
| Work Mode | AHVA, Normally Black, Transmissive |
| Used for | Industrial |
| Touchscreen | Without |
