| PartNumber | G101QAN01.0 |
| Brand | AUO |
| Size | 10.1 |
| Application | Industrial |
| Resolution | 1600×2560 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 10.1 inch |
| Pixel Format | 1600(RGB)×2560 [WQXGA] 300PPI |
| Active Area | 135.36(H)×216.576(V) mm |
| Luminance | - |
| View Direction | Symmetry |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Support Color | 16.7M |
| Weight | - |
| Frame Rate | 60Hz |
| Model | G101QAN01.0 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 142.96(H)×228.04(V) ×4.05(D) mm |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Response Time | 25 (Typ.)(Tr+Td) |
| Operating Mode | AHVA, Normally Black, Transmissive |
| Light Source | WLED , 15K hours , W/O Driver |
| Designed For | Industrial |
| Touch Panel | Without |
