HV101WU1-1E3


Brand
HYDIS
Size
10.1
Application
PAD
Resolution
1920×1200
Composition
LCM
Brightness
700
CR
750:1
Colors
16.7M
Backlight
WLED
Interface
LVDS/MIPI
In Stock
4751
Specifications
PartNumber HV101WU1-1E3
BrandHYDIS
Size10.1
ApplicationPAD
Resolution1920(RGB)×1200 , WUXGA
CompositionLCM
Brightness700 cd/m² (Typ.)
CR750:1
Colors16.7M
BacklightWLED
InterfaceLVDS/MIPI
Panel BrandHYDIS
Panel ModelHV101WU1-1E3 1 Compatible model
Panel Type a-Si TFT-LCD , LCM
Panel Size10.1 inch
Display ModeAFFS, Normally Black, Transmissive
Active Area216.576×135.36 mm
Outline229×153×4.8 mm
Surface
Contrast Ratio750:1 (Typ.)
Display Colors16.7M (8-bit)
Response Time30 (Typ.)(Tr+Td)
Viewing Angle89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequency60Hz
Lamp TypeWLEDEmbedded (LED Driver)
Signal InterfaceLVDS/MIPI, 45 pins
Input Voltage3.3V (Typ.)
Family Model
B101AW03 V0 AUO 10.1 1024×600
HSD101PFW4-A00 HannStar 10.1 1024×600
HV101WU1-1E3 HYDIS 10.1 1920×1200
LP101WH1-TLA3 LG Display 10.1 1366×768
LP101WS1-TLB3 LG Display 10.1 1024×576
LTN101AT03-801 Samsung 10.1 1366×768
M101NWWB R6 IVO 10.1 1280×800
N101L6-L02 Innolux 10.1 1024×600
N101L6-L0B Innolux 10.1 1024×600
P101KDA-AP1 Innolux 10.1 1200×1920
