| PartNumber | G156HAB01.0 |
| Brand | AUO |
| Size | 15.6 |
| Application | Industrial |
| Resolution | 1920(RGB)×1080, FHD, 141PPI |
| Composition | a-Si TFT-LCD , Assem |
| Brightness | 300 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.2M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | AUO |
| Panel Size | 15.6" |
| Display Area | 344.16(W)×193.59(H) mm |
| Outline Size | 361(W)×227(H) ×4.9(D) mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.2M 45% NTSC |
| Frequency | 60Hz |
| Panel Weight | 620g (Max.) |
| Signal Interface | eDP (2 Lanes) , eDP1.2 , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Model | G156HAB01.0 |
| Panel Type | a-Si TFT-LCD , Assembly |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Hard coating (7H) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Display Mode | - |
| Response Time | 25 (Typ.)(Tr+Td) |
| Lamp Type | WLED , 30K hours , With LED Driver |
| Touch Screen | On-Cell Touch |
