| PartNumber | G185XW01 V201 |
| Brand | AUO |
| Size | 18.5 |
| Application | Industrial |
| Resolution | 1366(RGB)×768, WXGA, 84PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 450 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | AUO |
| Panel Model | G185XW01 V201 |
| Panel Size | 18.5" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 409.8(W)×230.4(H) mm |
| Bezel Opening | 413.4(W)×234.0(H) mm |
| Outline Size | 430.4(W)×254.7(H) mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | - |
| Response Time | 3.5/1.5 (Typ.)(Tr/Td) |
| Display Colors | 16.7M 70% NTSC |
| Lamp Type | WLED , 50K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 1.44Kgs (Max.) |
| Signal Interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
| G185XW01 V1 | AUO | 18.5 | 1366×768 |
| G185XW01 V2 | AUO | 18.5 | 1366×768 |
| HM185WX1-400 | BOE | 18.5 | 1366×768 |
| LC185EXE-TEA1 | LG Display | 18.5 | 1366×768 |
| LC190WH1-TLC1 | LG Display | 18.5 | 1366×768 |
| LTA185AT01 | Samsung | 18.5 | 1366×768 |
| LTM185AT04 | Samsung | 18.5 | 1366×768 |
| M185XW01 V3 | AUO | 18.5 | 1366×768 |
| M185XW01 V4 | AUO | 18.5 | 1366×768 |
| M185XW01 V6 | AUO | 18.5 | 1366×768 |
