| PartNumber | G270ZAN01.3 |
| Brand | AUO |
| Size | 27.0 |
| Application | Industrial Medical I |
| Resolution | 3840×2160 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 10S8P WLED , 30K hours , No Driver |
| Interface | eDP |
| Manufacturer | AUO |
| Model Name | G270ZAN01.3 |
| Screen Size | 27.0 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 3840(RGB)×2160 (UHD) 163PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 596.16 × 335.34 (H×V) |
| Outline(mm) | 630 × 368.2 × 19.8 (H×V×D) |
| Bezel Area(mm) | 602.0 × 340.4 (H×V) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 16/25 (Typ./Max.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | AHVA, Normally Black, Transmissive |
| Color Depth | 16.7M 99% Adobe RGB |
| Mass | 3.30Kgs (Typ.) |
| Used for | Industrial Medical Imaging |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | eDP (4 Lanes) , HBR2 (5.4G/lane) , 51 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
