| PartNumber | GCX162AKM-7 |
| Brand | Sony |
| Size | 4.0 |
| Application | Mobile Phone |
| Resolution | 540×960 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MDDI/MIPI |
| Model | GCX162AKM-7 |
| Diagonal Size | 4.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 540(RGB)×960 [qHD] 277PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 49.41(H)×87.84(V) mm |
| Outline Dim. | 54.31(H)×99.505(V) mm |
| Bezel Area | - |
| Treatment | Hard coating |
| Luminance | 440 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) |
| Operating Mode | Vistarich, Normally Black, Transmissive |
| Support Color | 16.7M 72% NTSC |
| Light Source | WLED [9S1P] , W/O Driver |
| Weight | 18.8g (Typ.) |
| Designed For | Mobile Phone |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | MDDI/MIPI , 23 pins FPC |
| Power Supply | 1.8/3.0V (Typ.)(VDDIO/AVDD) |
| Environment | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
