| PartNumber | GT070WVM-N10-3GP0 |
| Brand | BOE |
| Size | 7.0 |
| Application | Industrial |
| Resolution | 800(RGB)×480, WVGA, 134PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 500 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 262K/16.7M |
| Backlight | WLED |
| Interface | |
| Panel Brand | BOE |
| Panel Size | 7.0" |
| Display Area | 154.08(W)×85.92(H) mm |
| Outline Size | 164.9(W)×100(H) ×6(D) mm |
| Viewing Angle | 75/75/60/75 (Typ.)(CR≥10) |
| Best View on | - |
| Display Colors | 262K/16.7M 50% NTSC |
| Frequency | 60Hz |
| Weight | 133±5g |
| Panel Model | GT070WVM-N10-3GP0 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | 157.08(W)×89.33(H) mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 25 (Typ.)(Tr+Td) |
| Lamp Type | WLED , Without Driver |
| Touch Screen | Without |
