| PartNumber | GV101WXM-N81 |
| Brand | BOE |
| Size | 10.1 |
| Application | Pad & Tablet Industrial |
| Resolution | 1280(RGB)×800, WXGA, 149PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Panel Brand | BOE |
| Panel Size | 10.1" |
| Display Area | 216.96(W)×135.6(H) mm |
| Outline Size | 228.3(W)×149.05(H) ×2.6(D) mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 48% NTSC |
| Frequency | 60Hz |
| Weight | 155g (Max.) |
| Panel Model | GV101WXM-N81 (BOE03F2) |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Glare (Haze 0%), Hard coating |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Display Mode | ADS, Normally Black, Transmissive |
| Response Time | 30 (Typ.)(Tr+Td) |
| Lamp Type | WLED , 15K hours , With LED Driver |
| Touch Screen | Without |
