| PartNumber | LP101WH4-SLA6 |
| Brand | LG Display |
| Size | 10.1 |
| Application | PAD |
| Resolution | 1366(RGB)×768 , WXGA |
| Composition | Assembly |
| Brightness | 400 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | LG Display |
| Panel Model | LP101WH4-SLA6 |
| Panel Type | a-Si TFT-LCD , Assembly |
| Panel Size | 10.1 inch |
| Active Area | 222.52×125.11 mm |
| Outline | 269.37×171.97×5.8 mm |
| Surface | |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | LVDS (1 ch, 8-bit), 39 pins |
| Input Voltage | 3.3V (Typ.) |
