| PartNumber | LP101WX2-SLA1 |
| Brand | LG Display |
| Size | 10.1 |
| Application | PAD |
| Resolution | 1280(RGB)×800 , WXGA |
| Composition | Assembly |
| Brightness | 360 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | LG Display |
| Panel Model | LP101WX2-SLA1 |
| Panel Type | a-Si TFT-LCD , Assembly |
| Panel Size | 10.1 inch |
| Active Area | 216.96×135.6 mm |
| Outline | 257.2×175.4×5.9 mm |
| Surface | Anti Fingerprint |
| Contrast Ratio | 500:1 (Min.) |
| Display Colors | 16.7M (6-bit + Hi-FRC) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | LVDS (1 ch, 8-bit), 40 pins |
| Input Voltage | 3.3V (Typ.) |
