| PartNumber | LSL080AL02-002 |
| Brand | Samsung |
| Size | 8.0 |
| Application | PAD |
| Resolution | 800(RGB)×1280 , WXGA |
| Composition | CELL |
| Brightness | 0 |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | MIPI |
| Panel Brand | SAMSUNG |
| Panel Model | LSL080AL02-002 |
| Panel Type | a-Si TFT-LCD , CELL |
| Panel Size | 8.0 inch |
| Display Mode | PLS, Normally Black, Transmissive |
| Active Area | 107.64×172.224 mm |
| Outline | 112.64×181.824×0.69 mm |
| Surface | Glare (Haze 0%), Hard coating |
| Glass Depth | 0.20+0.20 mm |
| Transmissivity | 6.6% (Typ.)(with Polarizer) |
| Contrast Ratio | 900:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 16 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | MIPI (4 data lanes), 34 pins |
| Input Voltage | 1.8/3.3V (Typ.)(DVDD/PVDD) |
