| PartNumber | HV089WU1-1E0 |
| Brand | HYDIS |
| Size | 8.9 |
| Application | PAD |
| Resolution | 1920(RGB)×1200 , WUXGA |
| Composition | LCM |
| Brightness | 450 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Panel Brand | HYDIS |
| Panel Model | HV089WU1-1E0 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 8.9 inch |
| Display Mode | HFFS, Normally Black, Transmissive |
| Active Area | 191.52×119.7 mm |
| Outline | 203.5×135.9×5 mm |
| Surface | Antireflection |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.7M (6-bit + Hi-FRC) |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 7S5PWLEDWithout Driver |
| Signal Interface | MIPI (4 data lanes), 45 pins |
| Input Voltage | 3.3V (Typ.) |
