| PartNumber | HV101HD1-1E2 |
| Brand | HYDIS |
| Size | 10.1 |
| Application | PAD |
| Resolution | 1366(RGB)×768 , WXGA |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | HYDIS |
| Panel Model | HV101HD1-1E2 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 10.1 inch |
| Display Mode | HFFS, Normally Black, Transmissive |
| Active Area | 223.341×125.568 mm |
| Outline | 234.53×138.97×4.4 mm |
| Surface | |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193150% |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 8-bit), 40 pins |
| Input Voltage | 3.3V (Typ.) |
| B101AW03 V0 | AUO | 10.1 | 1024×600 |
| B101AW03 V1 | AUO | 10.1 | 1024×600 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| BT101IW04 V.0 | Innolux | 10.1 | 1024×600 |
| HSD101PWW1-H00 | HannStar | 10.1 | 1280×800 |
| HT101WSB-100 | BOE | 10.1 | 1024×600 |
| HV101HD1-1E0 | HYDIS | 10.1 | 1366×768 |
| HV101HD1-1E2 | HYDIS | 10.1 | 1366×768 |
| LTN101NT02-W05 | Samsung | 10.1 | 1024×600 |
| N101BCG-L21 | Innolux | 10.1 | 1366×768 |
| B101UAN01.7 HW0A | AUO | 10.1 | 1920×1200 |
| BP082WX1-100 | BOE | 8.2 | 1280×800 |
| HJ101NA-02A | Innolux | 10.1 | 1280×800 |
| HX104X01-212 | HYDIS | 10.4 | 1024×768 |
| LD070WU1-SM01 | LG Display | 7.0 | 1200×1920 |
| LD080WX2-SMN1 | LG Display | 8.0 | 800×1280 |
| LP079QX1-SP0V | LG Display | 7.9 | 1536×2048 |
| LPM070W425D | JDI | 7.0 | 1200×1920 |
| LQ097L1JY01 | SHARP | 9.7 | 2048×1536 |
| TV096WXM-NS0 | BOE | 9.6 | 800×1280 |
