LP079QX1-SP0V


Brand
LG Display
Size
7.9
Application
PAD
Resolution
1536×2048
Composition
LCM
Brightness
420
CR
1000:1
Colors
16.7M
Backlight
WLED
Interface
eDP
In Stock
34
Specifications
PartNumber LP079QX1-SP0V
BrandLG Display
Size7.9
ApplicationPAD
Resolution1536(RGB)×2048 , QXGA
CompositionLCM
Brightness420 cd/m² (Typ.)
CR1000:1
Colors16.7M
BacklightWLED
InterfaceeDP
Panel BrandLG Display
Panel ModelLP079QX1-SP0V
Panel Type a-Si TFT-LCD , LCM
Panel Size7.9 inch
Display ModeIPS, Normally Black, Transmissive
Active Area119.802×159.717 mm
Outline129×171.05 mm
SurfaceGlare (Haze 0%), Hard coating (3H), Antireflection
Contrast Ratio1000:1 (Typ.)
Display Colors16.7M (8-bit)
Response Time16 (Typ.)(Tr+Td)
Viewing Angle80/80/80/80 (Typ.)(CR≥10)(L/R/U/D)
Frequency60Hz
Lamp Type6 stringsWLEDWithout Driver
Signal InterfaceeDP (4 Lanes), 32 pins
Input Voltage3.7V (Typ.)
Family Model
B079XAN02.0 CELL AUO 7.9 768×1024
B080XAN01.0 AUO 7.9 768×1024
B080XAN02.0 AUO 7.9 768×1024
LP079QX1-SP0V LG Display 7.9 1536×2048
LP079X01-SMA1 LG Display 7.9 768×1024
LQ079L1SX01 SHARP 7.9 1536×2048
LQ079L1SX02 SHARP 7.9 1536×2048
PA079DS1T2 E Ink 7.9 480×234
PA079DS1T3 E Ink 7.9 480×234
PA080XS4 E Ink 7.9 480×468
