| PartNumber | HSD050I551-A00 |
| Brand | HannStar |
| Size | 5.0 |
| Application | VDP |
| Resolution | 320(RGB)×234 |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 350:1 |
| Colors | |
| Backlight | CCFL |
| Interface | Analog |
| Panel Brand | HannStar |
| Panel Model | HSD050I551-A00 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 5.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 102.72×74.53 mm |
| Outline | 119.3×91.4×7.8 mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 350:1 (Typ.) |
| Display Colors | |
| Response Time | 5/20 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | TFT Specific Analog RGB, 30 pins |
| Input Voltage | 3/5/15/-10V (Typ.)(DVDD/AVDD/VGH/VGL) |
| RoHS: |
