| PartNumber | HSD090JFW1-A02 |
| Brand | HannStar |
| Size | 9.0 |
| Application | Automotive Display |
| Resolution | 1024×600 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 800:1 |
| Colors | 16.2M |
| Backlight | 3S13P WLED , 15K hours , No Driver |
| Interface | LVDS |
| Manufacturer | HannStar |
| Model Name | HSD090JFW1-A02 |
| Screen Size | 9.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1024(RGB)×600 (WSVGA) 132PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 196.608 × 114.15 (H×V) |
| Outline(mm) | 211.1 × 126.5 × 6 (H×V×D) |
| Bezel Area(mm) | 200.01 × 117.55 (H×V) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 17/18 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS Pro, Normally Black, Transmissive |
| Color Depth | 16.2M 50% NTSC |
| Mass | 226g (Typ.) |
| Used for | Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 8-bit) , FPC 40 pins |
| Voltage Supply | 3.3/12.5/23/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.9G (28.4 m/s²) |
