| PartNumber | HSD101BFW6-A00 |
| Brand | HannStar |
| Size | 10.1 |
| Application | Pad & Tablet |
| Resolution | 1024×600 |
| Composition | CELL, a-Si TFT-LCD |
| Brightness | |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | |
| Manufacturer | HannStar |
| Model Name | HSD101BFW6-A00 |
| Screen Size | 10.1 inch |
| Screen Type | CELL, a-Si TFT-LCD |
| Pixel Number | 1024(RGB)×600 (WSVGA) 117PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 222.72 × 125.28 (H×V) |
| Outline(mm) | 230.4 × 134.2 × 0.8 (H×V×D) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 10/20 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS Pro, Normally Black, Transmissive |
| Glass Thickness | 0.40+0.40 mm |
| Transmissivity | 5.81% (Typ.)(with Polarizer) |
| Color Depth | 16.7M 45% NTSC |
| Mass | - |
| Used for | Pad & Tablet |
| Refresh Rate | - |
| Touchscreen | Without |
| Driver IC list | Suggest COG EK79007AD, HX8282-C, EK73215BCGA, HX8696-A |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| B101AW01 V2 HW0A | AUO | 10.1 | 1024×576 |
| B101EAN01.7 | AUO | 10.1 | 1280×800 |
| B101UAN01.7 HW2A | AUO | 10.1 | 1920×1200 |
| BP101WX1-300 | BOE | 10.1 | 1280×800 |
| HSD100IFW1-A02 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-A00-C40 | HannStar | 10.1 | 1280×800 |
| LP101WH4-SLA6 | LG Display | 10.1 | 1366×768 |
| LP101WX1-SLB1 | LG Display | 10.1 | 1280×800 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
| VVX10F004B00 | Panasonic | 10.1 | 1920×1200 |
