| PartNumber | HT260WX1-100 |
| Brand | BOE |
| Size | 26.0 |
| Application | LCTV |
| Resolution | 1366(RGB)×768 , WXGA |
| Composition | LCM |
| Brightness | 450 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.2M |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | BOE |
| Panel Model | HT260WX1-100 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 26.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 575.769×323.712 mm |
| Outline | 626×373×43.5 mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.2M (6-bit + FRC) |
| Response Time | 5 (Typ.)(G to G) |
| Viewing Angle | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 4 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 30 pins |
| Input Voltage | 5.0V (Typ.) |
