| PartNumber | ITSX98 |
| Brand | IDTech |
| Size | 18.1 |
| Application | DMPC |
| Resolution | 1280(RGB)×1024 , SXGA |
| Composition | LCM |
| Brightness | 270 cd/m² (Typ.) |
| CR | 400:1 |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | IDTech |
| Panel Model | ITSX98 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 18.1 inch |
| Display Mode | DD-IPS, Normally Black, Transmissive |
| Active Area | 359.04×287.232 mm |
| Outline | 389×317.2 mm |
| Surface | |
| Contrast Ratio | 400:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 40 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 6 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Voltage | 12.0V (Typ.) |
