| PartNumber | KCB6448BSTT-X4 |
| Brand | Kyocera |
| Size | 10.4 |
| Application | IA |
| Resolution | 640(RGB)×480 , VGA |
| Composition | LCM |
| Brightness | |
| CR | 20:1 |
| Colors | Color |
| Backlight | CCFL |
| Interface | Parallel Data |
| Panel Brand | Kyocera |
| Panel Model | KCB6448BSTT-X4 |
| Panel Type | CSTN-LCD , LCM |
| Panel Size | 10.4 inch |
| Display Mode | STN, Normally Black, Transmissive |
| Active Area | 211.2×158.4 mm |
| Surface | |
| Contrast Ratio | 20:1 (Typ.) |
| Display Colors | Color , CIE193140% |
| Response Time | 160/80 (Typ.)(Tr/Td) |
| Viewing Angle | |
| Frequency | 75Hz |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | Parallel Data (2ch, 8-bit) |
| Input Voltage | 5.0V (Typ.) |
