| PartNumber | TCG121XGLPAPNN-AN20 |
| Brand | Kyocera |
| Size | 12.1 |
| Application | IA |
| Resolution | 1024(RGB)×768 , XGA |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 750:1 |
| Colors | 262K/16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | Kyocera |
| Panel Model | TCG121XGLPAPNN-AN20 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 12.1 inch |
| Display Mode | AWV, Normally Black, Transmissive |
| Active Area | 245.76×184.32 mm |
| Outline | 260.5×203.4×10.8 mm |
| Surface | Antiglare |
| Contrast Ratio | 750:1 (Typ.) |
| Display Colors | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| Response Time | 18/12 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 6/8-bit), 20 pins |
| Input Voltage | 3.3V (Typ.) |
