| PartNumber | LQ104V1DW02 |
| Brand | SHARP |
| Size | 10.4 |
| Application | IA |
| Resolution | 640(RGB)×480 , VGA |
| Composition | LCM |
| Brightness | 380 cd/m² (Typ.) |
| CR | 450:1 |
| Colors | 262K |
| Backlight | CCFL |
| Interface | TTL |
| Panel Brand | SHARP |
| Panel Model | LQ104V1DW02 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 10.4 inch |
| Display Mode | ASV, Normally Black, Transmissive |
| Active Area | 211.2×158.4 mm |
| Outline | 246.5×179.4×15.5 mm |
| Surface | Antiglare, Hard coating (3H), Antireflection |
| Contrast Ratio | 450:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 12/13 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Lamp Type | 2 pcsCCFLWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 31 pins |
| Input Voltage | 3.3/5.0V (Typ.)(VCC) |
| LQ104S1DG21 | SHARP | 10.4 | 800×600 |
| LQ104S1DG34 | SHARP | 10.4 | 800×600 |
| LQ104S1DG61 | SHARP | 10.4 | 800×600 |
| LQ104S1LG31 | SHARP | 10.4 | 800×600 |
| LQ104S1LG61 | SHARP | 10.4 | 800×600 |
| LQ104S1LG81 | SHARP | 10.4 | 800×600 |
| LQ104V1DG11 | SHARP | 10.4 | 640×480 |
| LQ104V1DG51 | SHARP | 10.4 | 640×480 |
| LQ104V1DG59 | SHARP | 10.4 | 640×480 |
| LQ104V1DG83 | SHARP | 10.4 | 640×480 |
| A150XN01 V0 | AUO | 15.0 | 1024×768 |
| DLC0570CDG-1 | Other | 5.7 | 320×240 |
| G057QN01 V0 | AUO | 5.7 | 320×240 |
| G190SF01 V0 | AUO | 19.0 | 1680×342 |
| KCS072VG1MB-G42 | Kyocera | 7.2 | 640×480 |
| LM8V311 | SHARP | 7.7 | 640×480 |
| LS037V3DX01 | SHARP | 3.7 | 640×480 |
| NL6448BC20-35D | NLT | 6.5 | 640×480 |
| NL8060BC21-11C | NLT | 8.4 | 800×600 |
| TM084SBHG04 | Tianma | 8.4 | 800×600 |
