| PartNumber | NL6448BC20-35D |
| Brand | NLT |
| Size | 6.5 |
| Application | IA |
| Resolution | 640(RGB)×480 , VGA |
| Composition | LCM |
| Brightness | 600 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | TTL |
| Panel Brand | NEC |
| Panel Model | NL6448BC20-35D |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 6.5 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 132.48×99.36 mm |
| Outline | 153×118 mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193140% |
| Response Time | 3/15 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 3 stringsWLEDWithout Driver |
| Signal Interface | CMOS (1 ch, 6-bit), 31 pins |
| Input Voltage | 3.3/5.0V (Typ.) |
