| PartNumber | KCS6448ESTT-X1 |
| Brand | Kyocera |
| Size | 7.7 |
| Application | Industrial |
| Resolution | 640×480 |
| Composition | LCM, CSTN-LCD |
| Brightness | |
| CR | 20:1 |
| Colors | Color |
| Backlight | CCFL |
| Interface | |
| Manufacturer | Kyocera |
| Model Name | KCS6448ESTT-X1 |
| Screen Size | 7.7 inch |
| Screen Type | LCM, CSTN-LCD |
| Pixel Number | 640(RGB)×480 (VGA) 103PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 157.42 × 118.06 (H×V) |
| Outline(mm) | 199 × 147 × 10.5 (H×V×D) |
| Bezel Area(mm) | 160.42 × 121.06 (H×V) |
| Treatment | Antiglare |
| Luminance | - |
| Contrast Ratio | 20 : 1 (Typ.) (TM) |
| Viewing Angle | 50/50/40/30 (Typ.)(CR≥2) |
| Response | 160/80 (Typ.)(Tr/Td) ms |
| Good View at | - |
| Work Mode | STN, Normally Black, Transmissive |
| Color Depth | Color |
| Mass | - |
| Used for | Industrial |
| Refresh Rate | 75Hz |
| Touchscreen | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
