| PartNumber | KG057QV1EB-G000 |
| Brand | Kyocera |
| Size | 5.7 |
| Application | Industrial |
| Resolution | 320×240, QVGA, 70PPI |
| Composition | STN-LCD, LCM |
| Brightness | - |
| CR | 4:1 |
| Colors | Monochrome |
| Backlight | CCFL |
| Interface | |
| Panel Brand | Kyocera |
| Panel Model | KG057QV1EB-G000 |
| Panel Size | 5.7" |
| Panel Type | STN-LCD, LCM |
| Pixel Format | Rectangle |
| Display Area | 115.18(W)×86.38(H) mm |
| Bezel Opening | - |
| Contrast Ratio | 4:1 (Typ.) (TM) |
| Viewing Angle | 45/45/20/40 (Typ.)(CR≥2) |
| Display Mode | STN, Blue mode (Negative), Transmissive |
| Best View on | - |
| Response Time | 380/120 (Typ.)(Tr/Td) |
| Display Colors | Monochrome |
| Lamp Type | CCFL |
| Frequency | - |
| Touch Screen | Without |
| Panel Weight | - |
| Environment | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
