| PartNumber | LA084X01-SL01 |
| Brand | LG Display |
| Size | 8.4 |
| Application | Automotive Display |
| Resolution | 1024(RGB)×768, XGA, 152PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | - |
| CR | 1100:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Panel Brand | LG Display |
| Panel Model | LA084X01-SL01 |
| Panel Size | 8.4" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 170.496(W)×127.872(H) mm |
| Bezel Opening | - |
| Contrast Ratio | 1100:1 (Typ.) (TM) |
| Viewing Angle | - |
| Display Mode | IPS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | - |
| Display Colors | 16.7M 60% NTSC |
| Lamp Type | WLED , 10K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | - |
| Panel Weight | - |
| Environment | Operating Temp.: -40 ~ 75 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 2.0G (19.6 m/s²) |
