| PartNumber | LA084X02-SL01 |
| Brand | LG Display |
| Size | 8.4 |
| Application | Automotive Display |
| Resolution | 1024×768 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.2M |
| Backlight | 10S3P WLED , No Driver |
| Interface | LVDS |
| Manufacturer | LG Display |
| Model Name | LA084X02-SL01 |
| Screen Size | 8.4 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1024(RGB)×768 (XGA) 152PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 170.496 × 127.872 (H×V) |
| Outline(mm) | 184.5 × 143 × 9.95 (H×V×D) |
| Luminance | 1200 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Response | 40 (Max.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS, Normally Black, Transmissive |
| Color Depth | 16.2M 70% NTSC |
| Mass | 255/260g (Typ./Max.) |
| Used for | Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 8-bit) , FPC 40 pins |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 2.84G (27.8 m/s²) |
