| PartNumber | LA090WH1-SL01 |
| Brand | LG Display |
| Size | 9.0 |
| Application | Automotive Display |
| Resolution | 1280×720 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Model | LA090WH1-SL01 |
| Diagonal Size | 9.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1280(RGB)×720 [WXGA] 164PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 200.448(H)×106.056(V) mm |
| Outline Dim. | 213.2(H)×121.2(V) ×8.6(D) mm |
| Bezel Area | 203.148(H)×108.756(V) mm |
| Treatment | Antiglare |
| Luminance | 600 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 17/13 (Max.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) |
| Operating Mode | IPS, Normally Black, Transmissive |
| Support Color | 16.7M 65% NTSC |
| Light Source | WLED [6S3P] , 10K hours , W/O Driver |
| Weight | 219/224g (Typ./Max.) |
| Designed For | Automotive Display |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 8-bit) , 60 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 95 °C |
