LC320EUD-SEM1


Brand
LG Display
Size
31.5
Application
LCTV
Resolution
1920×1080
Composition
LCM
Brightness
360
CR
1400:1
Colors
1.06B
Backlight
WLED
Interface
LVDS
In Stock
636
Specifications
PartNumber LC320EUD-SEM1
BrandLG Display
Size31.5
ApplicationLCTV
Resolution1920(RGB)×1080 , FHD
CompositionLCM
Brightness360 cd/m² (Typ.)
CR1400:1
Colors1.06B
BacklightWLED
InterfaceLVDS
Panel BrandLG Display
Panel ModelLC320EUD-SEM1
Panel Type a-Si TFT-LCD , LCM
Panel Size31.5 inch
Display ModeIPS, Normally Black, Transmissive
Active Area698.4×392.85 mm
Outline727.4×429 mm
SurfaceAntiglare (Haze 1%), Hard coating (2H)
Contrast Ratio1400:1 (Typ.)
Display Colors1.06B (8-bit + Dithering), CIE193172%
Response Time5 (Typ.)(G to G); 8 (Typ.)(MPRT)
Viewing Angle89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
Frequency120Hz
Lamp TypeWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (4 ch, 10-bit), 92 pins
Input Voltage12.0V (Typ.)
Family Model
LC320EUD-SCA1 LG Display 31.5 1920×1080
LC320EUD-SDA2 LG Display 31.5 1920×1080
LC320EUD-SDP1 LG Display 31.5 1920×1080
LC320EUE-SEM1 LG Display 31.5 1920×1080
LC320EUN-SDV1 LG Display 31.5 1920×1080
LC320EUN-SEF1 LG Display 31.5 1920×1080
LC320EUN-SFF1 LG Display 31.5 1920×1080
LC320EXN-FEP1 LG Display 31.5 1366×768
LC320EXN-SCA1 LG Display 31.5 1366×768
LC320EXN-SEA3 LG Display 31.5 1366×768
