LC320EXN-SEA3


Brand
LG Display
Size
31.5
Application
LCTV
Resolution
1366×768
Composition
LCM
Brightness
350
CR
1200:1
Colors
16.7M
Backlight
WLED
Interface
LVDS
In Stock
7613
Specifications
PartNumber LC320EXN-SEA3
BrandLG Display
Size31.5
ApplicationLCTV
Resolution1366×768(RGB) , WXGA
CompositionLCM
Brightness350 cd/m² (Typ.)
CR1200:1
Colors16.7M
BacklightWLED
InterfaceLVDS
Panel BrandLG Display
Panel ModelLC320EXN-SEA3
Panel Type a-Si TFT-LCD , LCM
Panel Size31.5 inch
Display ModeIPS, Normally Black, Transmissive
Active Area697.685×392.256 mm
Outline735.4×433 mm
SurfaceAntiglare (Haze 1%), Hard coating (3H)
Contrast Ratio1200:1 (Typ.)
Display Colors16.7M (6-bit + Dithering), CIE193168%
Response Time6 (Typ.)(G to G)
Viewing Angle89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
Frequency60Hz
Lamp TypeWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (1 ch, 8-bit), 30 pins
Input Voltage12.0V (Typ.)
