LC370WUN-SBA1


Brand
LG Display
Size
37
Application
LCTV
Resolution
1920×1080
Composition
LCM
Brightness
500
CR
1400:1
Colors
16.7M/1.06B
Backlight
EEFL
Interface
LVDS
In Stock
2227
Specifications
PartNumber LC370WUN-SBA1
BrandLG Display
Size37
ApplicationLCTV
Resolution1920(RGB)×1080 , FHD
CompositionLCM
Brightness500 cd/m² (Typ.)
CR1400:1
Colors16.7M/1.06B
BacklightEEFL
InterfaceLVDS
Panel BrandLG Display
Panel ModelLC370WUN-SBA1
Panel Type a-Si TFT-LCD , LCM
Panel Size37 inch
Display ModeS-IPS, Normally Black, Transmissive
Active Area819.36×460.89 mm
Outline877×516.8 mm
SurfaceAntiglare (Haze 10%), Hard coating (3H)
Contrast Ratio1400:1 (Typ.)
Display Colors16.7M/1.06B (8-bit / 8-bit + Dithering)
Response Time5 (Typ.)(G to G)
Viewing Angle89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequency60Hz
Lamp TypeEEFLEmbedded (Inverter)
Signal InterfaceLVDS (2 ch, 8/10-bit), 51 pins
Input Voltage12.0V (Typ.)
Family Model
LC370W01-A6 LG Display 37 1366×768
LC370WUB-SCB1 LG Display 37 1920×1080
LC370WUD-SBM2 LG Display 37 1920×1080
LC370WUE-SCA1 LG Display 37 1920×1080
LC370WUN-SAB1 LG Display 37 1920×1080
LC370WUN-SCA1 LG Display 37 1920×1080
LC370WUN-SCC1 LG Display 37 1920×1080
LC370WX1-SL01 LG Display 37 1366×768
LC370WXE-SDP1 LG Display 37 1366×768
LC370WXN-SBD1 LG Display 37 1366×768
