| PartNumber | LD470DXS-SCB1 |
| Brand | LG Display |
| Size | 47 |
| Application | DID |
| Resolution | 1366(RGB)×768 , WXGA |
| Composition | LCM |
| Brightness | 500 cd/m² (Typ.) |
| CR | 1400:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | LG Display |
| Panel Model | LD470DXS-SCB1 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 47 inch |
| Display Mode | S-IPS, Normally Black, Transmissive |
| Active Area | 1039.87×584.64 mm |
| Outline | 1046.8×591.6×50.5 mm, Videowall Seam 6.9 mm |
| Surface | Antiglare (Haze 10%), Hard coating (3H) |
| Contrast Ratio | 1400:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Response Time | 12 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 8-bit), 30 pins |
| Input Voltage | 12.0V (Typ.) |
