| PartNumber | LH470WX6-SD01 |
| Brand | LG Display |
| Size | 4.7 |
| Application | MPH |
| Resolution | 750(RGB)×1334 , WXGA |
| Composition | Assembly |
| Brightness | 550 cd/m² (Typ.) |
| CR | 1600:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Panel Brand | LG Display |
| Panel Model | LH470WX6-SD01 |
| Panel Type | LTPS TFT-LCD , Assembly |
| Panel Size | 4.7 inch |
| Active Area | 58.5×104.052 mm |
| Outline | 61.61×135.77×2.22 mm |
| Surface | |
| Contrast Ratio | 1600:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | MIPI (3 data lanes), 30 pins |
| Input Voltage | 1.8/1.8/5.7/-5.7V (Typ.)(DVDD/DPHYVDD/AVDDH/AVDDN) |
