| PartNumber | LS038Y7DX01 |
| Brand | SHARP |
| Size | 3.8 |
| Application | MPH |
| Resolution | 480(RGB)×800 , WVGA |
| Composition | LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | TTL |
| Panel Brand | SHARP |
| Panel Model | LS038Y7DX01 |
| Panel Type | CG-Silicon , LCM |
| Panel Size | 3.8 inch |
| Display Mode | Normally Black, Transflective |
| Active Area | 49.68×82.8 mm |
| Outline | 54.6×93 mm |
| Surface | |
| Contrast Ratio | 500:1 (Typ.)(Transmissive)12:1 (Typ.)(Reflective) |
| Display Colors | 262K (6-bit), CIE193170% |
| Response Time | 40/40 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 7S1PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit) + SPI, 50 pins |
| Input Voltage | 3.85/1.8V (Typ.)(VDC/VDDIO) |
| RoHS: |
