| PartNumber | LM057QB1T09 |
| Brand | SHARP |
| Size | 5.7 |
| Application | IA |
| Resolution | 320×240 , QVGA |
| Composition | LCM |
| Brightness | |
| CR | |
| Colors | Monochrome |
| Backlight | |
| Interface | Parallel Data |
| Panel Brand | SHARP |
| Panel Model | LM057QB1T09 |
| Panel Type | STN-LCD , LCM |
| Panel Size | 5.7 inch |
| Display Mode | STN, Blue mode (Negative), Transmissive |
| Active Area | 115.17×86.37 mm |
| Surface | |
| Contrast Ratio | |
| Display Colors | Monochrome |
| Response Time | 190/210 (Typ.)(Tr/Td) |
| Viewing Angle | 40/40/25/40 (Typ.)(CR≥2)(L/R/U/D) |
| Lamp Type | |
| Signal Interface | Parallel Data (4-bit) |
