| PartNumber | LM171WX3-TLB2 |
| Brand | LG Display |
| Size | 17.1 |
| Application | DMPC |
| Resolution | 1440(RGB)×900 , WXGA+ |
| Composition | LCM |
| Brightness | |
| CR | |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | LG.Philips LCD |
| Panel Model | LM171WX3-TLB2 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 17.1 inch |
| Display Mode | Transmissive |
| Active Area | 367.2×229.5 mm |
| Surface | |
| Contrast Ratio | |
| Display Colors | 16.7M (6-bit + Hi-FRC), CIE193160% |
| Response Time | |
| Viewing Angle | |
| Frequency | 60Hz |
| Lamp Type | 2 pcsCCFL |
| Signal Interface | LVDS (2 ch, 8-bit) |
| RoHS: |
